On off, Off on – Twin City TCPE, WPB, WPD Propeller Wall Fans - IM-4800 User Manual
Page 7
Twin City IM-4800
7
WALL COLLAR WITH ACCESSORIES — TCPE
Mounting Screw
Fan
Wall Collar
Backdraft Damper
Weatherhood
or
Damper
Guard
ON
OFF
Variable
Speed Control
(Optional)
Disconnect Switch
(Optional)
OFF
ON
Removable Screen
Panel Fan
OSHA Motor
Side Guard
Backdraft Damper
Weatherhood
Damper Guard
Bird Screen
Wall Collar
Disconnect
Switch
OFF
ON
Removable Screen
Panel Fan
Wall Box
Backdraft Damper
Weatherhood
Bird Screen
Damper Guard
Disconnect
Switch
WALL COLLAR WITH ACCESSORIES — WPB, WPD
WALL BOX WITH ACCESSORIES — WPB, WPD
