5
❍ 2 oz. [57g] spray CA activator (GPMR6035)
❍ 4 oz. [113g] aerosol CA activator (GPMR6034)
❍ CA applicator tips (HCAR3780)
❍ CA debonder (GPMR6039)
❍ Epoxy brushes 6, (GPMR8060)
❍ Mixing sticks (GPMR8055)
❍ Mixing cups (GPMR8056)
❍ Pliers with wire cutter (HCAR0630)
❍ Compressed Air 10 oz (TAEC1060)
❍ Microballoons (TOPR1090)
❍ Switch & Charge Jack Mounting Set
(GPMM1000)
❍ Ernst Charge Receptacle Futaba J (ERNM3001)
❍ Rotary tool such as Dremel
®
❍ Rotary tool reinforced cut-off wheel (GPMR8020)
❍ Servo horn drill (HCAR0698)
❍ Hobby Heat
™ micro torch (HCAR0750)
❍ Dead Center ™ Engine Mount Hole Locator
(GPMR8130)
❍ AccuThrow ™ Defl ection Gauge (GPMR2405)
❍ CG Machine ™ (GPMR2400)
❍ Great Planes Heat Shrink Tubing 3/8x3" (3)
(GPMM1060)
❍ Ernst Security Clips Universal (2) (ERNM3035)
❍ Precision Magnetic Prop Balancer (TOPQ5700)
❍ Hobbico Flexible 18" Ruler Stainless Steel
(HCAR0460)
❍ Hobbico Pin Vise 1/16 Collet w/6 Bits
(HCAR0696)
❍ Hobbico 8-Piece Ball Tip Hex L Wrench SAE
(HCAR0520)
❍ Hobbico 7-Piece Ball Tip Hex L Wrench Metric
(HCAR0521)
❍ Great Planes Precision Prop Reamer Standard
(GPMQ5006)
❍ Great Planes Precision Prop Reamer Metric
(GPMQ5007)
❍ Great Planes Clevis Installation Tool
(GPMR8030)
❍ X-Acto ® Extra Hands Double Clip (XACR4214)
❍ Woodland Scenics Low Temp Foam Glue Gun
(WOOU1445)
IMPORTANT BUILDING NOTES
● There are two types of screws used in this kit:
Sheet Metal Screws are designated by a number
and a length. For example #6 x 3/4" [19mm].
This is a number six screw
that is 3/4" [19mm] long.
Machine Screws are designated by a number,
threads per inch, and a length. For example
4-40 x 3/4" [19mm].
This is a number four screw
that is 3/4" [19mm] long
with forty threads per inch.
● When you see the term test fi t in the instructions, it
means that you should fi rst position the part on the
assembly
without using any glue , then slightly
modify or custom fi t the part as necessary for the
best fi t.
● Whenever the term glue is written you should rely
upon your experience to decide what type of glue
to use. When a specifi c type of adhesive works
best for that step, the instructions will make a
recommendation.
● Whenever just epoxy is specifi ed you may use
either 30-minute (or 45-minute) epoxy or 6-minute
epoxy. When 30-minute epoxy is specifi ed it is
highly recommended that you use only 30-minute
(or 45-minute) epoxy, because you will need the
working time and/or the additional strength.
● Photos and sketches are placed before the
step they refer to. Frequently you can study
photos in following steps to get another view of
the same parts.
KIT INSPECTION
Before starting to build, take an inventory of this kit
to make sure it is complete, and inspect the parts to
make sure they are of acceptable quality. If any parts
are missing or are not of acceptable quality, or if you
need assistance with assembly, contact
Product
Support . When reporting defective or missing parts,
use the part names exactly as they are written in the
Kit Contents list.
Top Flite Product Support
3002 N Apollo Drive, Suite 1
Champaign, IL 61822
Ph: (217) 398-8970, ext. 5
Fax: (217) 398-7721
E-mail: airsupport@top-fl ite.com
ORDERING
REPLACEMENT PARTS
Replacement parts for the Top Flite P-40 Warhawk
ARF are available using the order numbers in the
Replacement Parts List that follows. The fastest,
most economical service can be provided by your
hobby dealer or mail-order company. Not all parts
are available separately. Replacement parts are not
available from Product Support, but can be purchased
from hobby shops or mail order/Internet order fi rms.
Hardware items (screws, nuts, bolts) are also available
from these outlets.
To locate a hobby dealer, visit www.top-fl ite.com
and click on “Where to Buy”. Follow the instructions
provided on the page to locate a U.S., Canadian or
International dealer.
Parts may also be ordered directly from Hobby
Services by calling (217) 398-0007, or via facsimile
at (217) 398-7721, but full retail prices and shipping
and handling charges will apply. Illinois and Nevada
residents will also be charged sales tax. If ordering
via fax, include a Visa
® or MasterCard ® number and
expiration date for payment.
Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822
