5. SPECIFICATIONS

Model No.

PE-304BU

PE-304WU

PE-604BU

PE-604WU

Enclosure

Bass-reflex type

Rated Input

30 W (100 V line, 70 V line, 8 Ω), 3.7 W (25 V line)

60 W (100 V line, 70 V line, 8 Ω), 7.5 W (25 V line)

Rated

Impedance

100 V line

330 Ω (30 W), 1 kΩ (10 W), 3.3 kΩ (3 W),

10 kΩ (1.3 W)

170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 3.3 kΩ (3 W)

70 V line

170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W),

10 kΩ (0.6 W)

83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W),

670 Ω (7.5 W), 3.3 kΩ (1.5 W)

25 V line

170 Ω (3.7 W), 330 Ω (1.9 W), 1 kΩ (0.6 W),

3.3 kΩ (0.2 W), 10 kΩ (0.1 W)

83 Ω (7.5 W), 170 Ω (3.7 W), 330 Ω (1.9 W),

670 Ω (0.9 W), 3.3 kΩ (0.2 W)

Low

8 Ω

Sensitivity

90 dB (1 W, 1 m) (330 Hz – 3.3 kHz, pink noise)

Frequency Response

95 Hz – 20 kHz (–10 dB)

110 Hz – 20 kHz (–10 dB)

Operating Temperature

–10 °C to +50 ℃ (14 ℉ to 122 ℉)

Speaker Component

12 cm (5") cone-type + balanced dome-tweeter (coaxial)

UL Code

UL 1480 UUMW, ULC-S541

Speaker Cable

4-core FPL listed cable 4.6 m (15.09 ft)

Finish

Enclosure:

ABS resin, black

Grille:

Surface-treated steel

plate mesh, black, paint

Enclosure:

ABS resin, white

(RAL 9010 equivalent)

Grille:

Surface-treated steel

plate mesh, white

(RAL 9010 equivalent),

paint

Enclosure:

ABS resin, black

Grille:

Surface-treated steel

plate mesh, black, paint

Enclosure:

ABS resin, white

(RAL 9010 equivalent)

Grille:

Surface-treated steel

plate mesh, white

(RAL 9010 equivalent),

paint

Dimensions

ø186 x 275 (h) mm (ø7.32" x 10.83") (unit only)

Weight

2 kg (4.41 lb) (unit only)

2.9 kg (6.39 lb) (unit only)

[Sound pressure level at 10 ft]

Model No.

PE-304BU, PE-304WU

PE-604BU, PE-604WU

Impedance

170 Ω 330 Ω

1 kΩ

3.3 kΩ 10 kΩ

83 Ω

170 Ω 330 Ω 670 Ω 3.3 kΩ

100 Vrms Wattage tap (W)

30

10

3

1.3

60

30

15

3

SPL per UL Reverberant Room (dBA)

92

88.7

83.1

78.6

93.1

91.1

89

82.3

SPL per ULC Anechoic Room (dBA)

96.4

90.2

85.4

81.9

95.1

93.5

90.9

83.8

70 Vrms Wattage tap (W)

30

15

5

1.5

0.6

60

30

15

7.5

1.5

SPL per UL Reverberant Room (dBA)

91.6

90.1

85.6

80.8

75.3

93.2

90.6

89.2

85.7

80

SPL per ULC Anechoic Room (dBA)

84.7

92.2

87.6

82.8

79.1

95

93.2

90.9

88.1

80.9

25 Vrms Wattage tap (W)

3.7

1.9

0.6

0.2

0.1

7.5

3.7

1.9

0.9

0.2

SPL per UL Reverberant Room (dBA)

83.4

80.7

76.3

71.8

66.1

84.7

83

80.5

77.1

71.1

SPL per ULC Anechoic Room (dBA)

86.5

83.8

78.9

74.1

70.4

87.2

85.1

82.4

79.4

72.1

8 Ω

SPL per UL Reverberant Room (dBA)

91.7

94

SPL per ULC Anechoic Room (dBA)

95.5

95.8

[Directional Characteristics]

Angle

dBA

0° (on axis)

0 (reference)

± 29°

–3

± 45°

–6

± 90°

–13

Note: The design and specifications are subject to change without notice for improvement.
• Accessories

URL: http://www.toa.jp/

533-06-267-00

Traceability Information for Europe

Manufacturer:

TOA Corporation

7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo, Japan

Authorized representative:

TOA Electronics Europe GmbH

Suederstrasse 282, 20537 Hamburg, Germany

GRIPPLE

®

No. 1* (preinstalled on the safety wire) ............... 1

GRIPPLE

®

No. 2* (preinstalled on the hanging wire) ............ 1

Release key (for GRIPPLE

®

) ................................................ 1

Safety wire (5 m or 16.4 ft, ø1.5 mm or 0.06") ...................... 1

Hanging wire (5 m or 16.4 ft, ø2 mm or 0.08") ...................... 1

Speaker cable (4-core FPL listed cable 4.6 m or 15.09 ft) .... 1

* GRIPPLE

®

No. 1 and No. 2 are hangers for suspending the speaker.

This manual is related to the following products:
