The BS-61WA and BS-61WT-A, each of which cabinet is made of wood, can be installed easily on the wall with help of the
plug-in speaker receptacle.
BS-61WA, BS-61WT-A
BI-DIRECTIONAL BOX SPEAKERS
INSTRUCTION MANUAL
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read
all the instructions in this section for correct and
safe operation.
• Be sure to follow all the precautionary instructions
in this section, which contain important warnings
and/or cautions regarding safety.
• After reading, keep this manual handy for future
reference.
• Install the unit only in a location that can
structurally support the weight of the unit and the
mounting bracket. Doing otherwise may result in
the unit falling down and causing personal injury
and/or property damage.
• Do not use other methods than specified to mount
the bracket. Extreme force is applied to the unit
and the unit could fall off, possibly resulting in
personal injuries.
• Tighten each nut and bolt securely. Ensure that the
bracket has no loose joints after installation to
prevent accidents that could result in personal
injury.
• Use the specified In-wall electrical box in
combination. Doing otherwise may cause the unit
or component to fall off, resulting in personal injury.
• Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
• Do not stand or sit on, nor hang down from the unit
as this may cause it to fall down or drop, resulting
in personal injury and/or property damage.
2. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
Model Number BS-61WA BS-61WT-A
Input 6 W
Input Impedance 1.7 kΩ (6 W), 5 kΩ (2 W)
Frequency Response 130 – 13,000 Hz
Sound Pressure Level 92 dB (1 W, 1 m)
Coverage Angle 100º
Speaker Component 16 cm (6") cone-type speaker, 2 pcs.
Volume Control 0 (Off), 1 (Low), 2 (Middle), 3 (High)
Finish Enclosure: Wood, off-white
Grille:
Cloth, off-white
Dimensions 200 (w) x 290 (h) x 220 (d) mm 200 (w) x 292 (h) x 220 (d) mm
(7.87" x 11.42" x 8.66") (7.87" x 11.50" x 8.66")
Weight 2.8 kg (6.17 lb) 2.9 kg (6.39 lb)
Accessories Machine screw M4 x 35 ... 2, Tapping screw 4 x 35 ... 2, Speaker receptacle ... 1
Optional Products Suspension Bracket: YS-31W
