12.2. Impedance Detection Module VX-200SZ-2
• Optional product
Equaliser card: VX-200SE
• Accessory
Plug-in screw terminal ............................... 1
Note: The design and specifications are subject to change without notice for improvement.
Power Source
Supplied from VX-2000SF
Current Consumption
Under 170 mA
Power Amplifier Link
RJ45 female connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier.
Twisted-pair straight cable (TIA/EIA-568A standard)
External Attenuator
Control Output
Plug-in screw connector, relay, no-voltage make contact output,
transfer type, withstand voltage: 30 V DC, 250 V AC,
contact current: Under 7 A (DC), under 7 A (AC)
Applicable cable diameter: AWG 24 – AWG 16
Speaker Output
2 outputs (A, B), plug-in screw connector
Applicable cable diameter: AWG 24 – AWG 16
Power Amplifier Input
Plug-in screw connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Applicable cable diameter: AWG 24 – AWG 16
Fault Detection System
Short circuit, open circuit (impedance detection method), ground fault
Finish
Panel: Surface-treated steel plate
Dimensions
30.5 (w) x 132.6 (h) x 290.3 (d) mm
Weight
335 g
Applicable Model
VX-2000SF
