19
Note
Regarding the "Open Circuit Occurrence" information, identify the speaker line failure by checking the speaker
line A and B status indicators on the module's front panel. (Refer to p. 8 .)
SP* Ground Fault Occurrence
[VX-200SP-2]
Log
Possible Cause
Additional Information Detail code
SP* Open Circuit Occurrence SP Monitor Speaker line disconnected
End-of-line unit failed
Speaker line shorted (far end)
Check for the speaker, its connection,
cable, and End-of-line unit.
SP* Short Circuit Occurrence Speaker line shorted
Solution
Speaker line grounded
* A speaker Zone number is displayed here.
SP* Ground Fault Occurrence
[VX-200SZ-2]
Log
Possible Cause
Additional Information Detail code
SP* Open Circuit Occurrence SP Monitor Speaker line A disconnected
Speaker line B disconnected
Speaker line A shorted
Speaker line B shorted
Check for the speaker, its connection,
and cable.
SP* Short Circuit Occurrence Speaker line A and B shorted
Solution
Speaker line grounded
* A speaker Zone number is displayed here.
10. MONITOrING LOG LIST
Possible causes of detected failures can be confirmed in the View Log window.
For reading out the log file, refer to the VX-2000 series Instruction manual.
Table below lists failure logs, possible causes, and their solutions.
