14
28 V 4.8 A
DC POWER IN
CH1
CH2
PA LINK
PA LINK
SP OUT B
PA IN
PA LINK
H
C
H
C
SP OUT A HC
SP OUT
PA IN
PA LINK
H
C
H
C
LINE MONITOR HC
1
1 n
n
1
n
RJ45 male connector
VX-200SZ-2
VX-200SP-2
From VX-2000DS'
or VX-3000DS'
DC POWER OUT
VX-2000SF
Cat. 5 STP
Cat. 5 STP
Shield
[VP-2122 Rear]
VP-200VX
VP-200VX
PA OUT (SP LINK)
C H
CH1
C H
CH2
End-of-line unit
7.1. VX-200SP-2 and VX-200SZ-2 Connection to Power Amplifier and Speakers
7. CONNECTIONS
Note
After bundling all the speaker shield cables from the individual VX-200SP-2 modules into one
cable at a terminal board, connect the cable to the VX-2000SF's chassis ground.
[When VP-2122 is used]
