22
12.1. Pilot Tone Detection Module VX-200SP-2
[End-of-line unit (accessory)]
• Optional product
Equaliser card: VX-200SE
• Accessories
Plug-in screw terminal ............................... 1
End-of-line unit .......................................... 1
Note: The design and specifications are subject to change without notice for improvement.
12. SPECIFICATIONS
Power Source Supplied from VX-2000SF
Current Consumption Under 100 mA
Power Amplifier Link RJ45 female connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Twisted-pair straight cable (TIA/EIA-568A standard)
Line Monitor Plug-in screw connector
Applicable cable diameter: AWG 24 – AWG 16
External Attenuator
Control output
Plug-in screw connector, relay, no-voltage make contact output,
transfer type, withstand voltage: 30 V DC, 250 V AC,
contact current: Under 7 A (DC), under 7 A (AC)
Applicable cable diameter: AWG 24 – AWG 16
Speaker Output Plug-in screw connector
Applicable cable diameter: AWG 24 – AWG 16
Power Amplifier Input Plug-in screw connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Applicable cable diameter: AWG 24 – AWG 16
Fault Detection System Short circuit, open circuit (pilot tone detection method), ground fault
Finish Panel: Surface-treated steel plate
Dimensions 30.5 (w) x 132.6 (h) x 290.3 (d) mm
Weight 235 g
Applicable Model VX-2000SF
Power Source Supplied from VX-200SP-2 (Generated by 40 Hz sine wave)
Speaker Line Input Screw connector, Applicable cable diameter: AWG 24 – AWG 16
Operation Mode Normal: Terminated by 470 kΩ between the speaker line and the shield
Open: Opened between the speaker line and the shield
Dimensions 70 x 45 mm
Weight 22 g
