Toa VX-200SZ-2 - Manual (Page 15)

15
SP OUT B
PA IN
PA LINK
H
C
H
C
SP OUT A HC
SP OUT
PA IN
PA LINK
H
C
H
C
LINE MONITOR HC
1
1 n
n
1
n
RJ45 male connector
VX-200SZ-2
VX-200SP-2
From VX-3000DS'
DC POWER OUT
VX-2000SF
Cat. 5 STP
Cat. 5 STP
Shield
[VP-3304 Rear]
End-of-line unit
-
+
Note
After bundling all the speaker shield cables from the individual VX-200SP-2 modules into one
cable at a terminal board, connect the cable to the VX-2000SF's chassis ground.
[When VP-3304 is used]
