9.4. Source Equipment Connections
When using a timer to activate source equipment to play a time signal chime or broadcast commercial
messages, connect the equipment's "Play on" output to the Timer or AUX control terminal of the JP-0410's
front-mounted terminal block.
Timer
GND
GND
GND
GND
GND
GND
24 V CHIME
ACTI
GEM RM PWR
1
1
2
2
3
4
5
6
7
8
1
9
10
IN USE
REMOTE REMOTE
TIMER
GEN RM BUS
PWR FAIL
CTRL
AUX CONTROL
JP-0410 front-mounted middle row terminal block
Control output
Input*
Source equipment
Play on output*
To pre-amplifier
Timer
GND
GND
GND
GND
GND
GND
24 V CHIME
ACTI
GEM RM PWR
1
1
2
2
3
4
5
6
7
8
1
9
10
IN USE
REMOTE REMOTE
TIMER
GEN RM BUS
PWR FAIL
CTRL
AUX CONTROL
JP-0410 front-mounted middle row terminal block
Control output
Input*
Source equipment
Play on output*
To pre-amplifier
Equipment name
Model No.
Input terminal
Play on output terminal name
Digital Announcer
EV-350P/-350R
Start 1, 2
Busy
[Connection to the Timer terminal]
[Connection to the AUX terminal]
* The "Play on" terminal refers to the terminal that is at make while the equipment is playing. The following
table shows the relationship of the input to "Play on" terminals of the source equipment to be connected.
