General Specifications A-4
Sound Blaster
Audigy 2 Platinum
eX External I/O
Module
Inputs and outputs on
front panel ❑ One headphone output with auto detection via ¼” stereo jack with volume control
❑ One shared line-level analog Line/Microphone input (Line-In 1/Mic-In) via ¼” stereo jack. Shared
input selectable via knob. Gain/level control for microphone
❑ One standalone line-level analog input (Line-In 2)
❑ Two optical connectors for optical SPDIF input and output
❑ One SB1394/FireWire connector for IEEE1394 compatible devices
❑ One infrared receiver for receiving information from the remote control. Transmission range within 4
meters with 15-degree deviation from the center axis.
Inputs and outputs on
rear panel ❑ One AD_LINK 1 connector for linking to the audio card
❑ One AD_LINK 2 (SB1394/FireWire) connector for power supply to the External I/O Module
❑ 1 x standard MIDI OUT and 1 x standard MIDI In jack for MIDI instruments
❑ One SB1394/FireWire port for connection to IEEE1394 compatible devices
❑ One Mini-DIN SPDIF digital output
❑ Two RCA jacks for Auxiliary Line Input (Line-In 3)
❑ Two RCA connectors for coaxial SPDIF input and output
