About your Sound Blaster Audigy 2 Platinum eX hardware 1-2
Your Sound
Blaster Audigy 2
Platinum eX card Your audio card has these jacks and connectors to enable the attachment of a wide variety of devices:
Click any circled number in the
diagram to see a description of the
item.
The Audigy 2 Platinum eX card
works as a stand-alone audio card.
However to enjoy all the features
available, you need to connect it to
the External I/O Module.
Figure 1-2: Jacks, connectors and ports
