About your Sound Blaster Audigy 2 Platinum eX hardware 1-3
Your Audigy 2
Platinum eX
External I/O
Module Your Sound Blaster Audigy 2 Platinum eX External I/O Module has these jacks, connectors and controls:
Click any circled number in the
diagram to see a description of
the item.
Figure 1-3: Jacks, connectors and controls.
10 11 12 13 14 15
1 2 3 4 5 6 7 8 9
• To connect your existing
computer headphones and
microphone to the External I/
O Module, use a 3.5 mm (1/
8”) minijack to 1/4” plug
adapter.
• Set the gain level of the Mic In
2 jack to the minimum before
connecting or turning on a
microphone, especially if you
are using headphones.
