About your Sound Blaster Audigy 2 Platinum eX hardware 1-5
Table 2: Audigy 2 Platinum eX External I/O Module
Number Description
1 SB1394/FireWire port
Connects to an IEEE 1394 compatible external device (such as a digital video
camcorder, digital still camera, printer or scanner).
2 Optical SPDIF Out/In
For recording/playback devices with optical connectors.
3 Line In 2 jack
For analog devices like music synthesizers and other line-level sources.
4 Line In 1/Mic In jack
For line sources (for example, electric guitars) or dynamic microphones.
5 ¼-inch Headphone jack
For connecting to headphones. (Speaker output will be muted).
6 Microphone Input Sensitivity control knob
Controls the input level of a microphone signal.
7 Master Volume control knob
Controls the overall output volume.
8 CMSS Switch
Turns the Creative MediaSource MultiSpeaker Surround ® feature on or off.
9 Infrared Receiver
Lets you control your computer via the IR remote control.
