About your Sound Blaster Audigy 2 Platinum eX hardware 1-6
10 Line In 3 (Aux In) jacks
Connects to analog devices like VCRs, TVs and CD players.
11 Standard MIDI In/Out connectors
Connects to MIDI devices via standard DIN cables.
12 SPDIF In/Out Coaxial jacks
For digital audio recording/playback devices such as DAT and MiniDisc recorders.
13 SPDIF Digital Out Mini DIN jack
Outputs digital audio via mini DIN cable.
14 AD_LINK 1 Connector
Connects to the Sound Blaster Audigy 2 Platinum eX card's AD_LINK 1 cable's
connector.
15 AD_LINK 2 Connector (SB1394/FireWire port)
Connects to the Sound Blaster Audigy 2 Platinum eX card's AD_Link 2 connector
via the supplied 1.8 meter (5-feet) AD_LINK cable. It provides power to the External
I/O Module. Next to AD_LINK 2 is another SB1394/ FireWire port, for connection
to IEEE1394-compatible devices.
Table 2: Audigy 2 Platinum eX External I/O Module
Number Description
Click here or on any description
to return to the diagram of the
External I/O Module.
