Tie Down G5 User Manual
Page 11

G5 - Stainless Steel Disc Brake Kits 9.6”
11.5”
12”
Replacement Kits:
Ceramic Brake Pad Kit (Consumer Aftermarket)
81252
Ceramic Brake Pad Kit (OEM)
81114
Caliper Rebuild Kit
46304RB
1 - Piston (#2A)
1 - Piston Rubber Boot (#2B)
1 - Piston Seal (#2C)
2 - Bronze Busings (#2D)
1 Stainless Steel Rotor w/GalvXL Hub
46911X
46914XA
46912X
2 Caliper Assembly
46910A
46910A
46910A
2A Piston
42080AZ
42080AZ
42080AZ
2B Piston Rubber Boot
17472
17472
17472
2C Piston Seal
17447
17447
17447
2D Bronze Busings
10010
10010
10010
3 Ceramic/Stainless Steel Brake Pads
11350/51
11350/51
11350/51
4 Adjustable Banjo Assembly
11341
11341
11341
4A Stainless Steel Banjo Bolt
11338
11338
11338
4B Copper Crush Washer
11339
11339
11339
4C Brass Banjo Fitting
11348
11348
11348
4D O-Ring
17473
17473
17473
5 Stainless Steel Bleed Valve(1)
11246SS
11246SS
11246SS
6 Stainless Steel Slider Pins (2)
12114
12114
12114
7 Mounting Bracket
with slider pins installed
44687GA
70518X
44688GA
8 Dust Cap
17094
46494
46494
Super Lube Dust Cap
17093
46495
46495
Super Lube Rubber Grommet
46963
46963
46963
9 Cotter Pin 1/8” x 1-3/4” Zinc
10551
10551
10551
10 Castle Nut - 6 position
10665
10665
10665
10 Castle Nut - 12 position
10634
10634
10634
11 Washer - Flat Spindle 1”
10520
10520
10520
12 Bearing Outer (Cone) 1-1/16” (L44649)
11054
----
----
Bearing Outer (Cone) 1-1/4” (15123)
----
11056
11056
13 Cup Outer (Race) 1-1/16” (L44610)
11055
----
----
Cup Outer (Race) 2-1/2” (15245)
----
11066
11066
14 Studs 1/2”- 20 x 2.0” OAL
11123
11133
11133
15 Cup Inner (Race) 1-3/8” (L68111)
11061
----
----
Cup Inner (Race) 3.27” (25520)
----
11067
11067
16 Bearing Inner (Cone) 1-3/8” (L68149)
11060
----
----
Bearing Inner (Cone) 1-3/4” (25580)
----
11064
11064
17 Seal - Triple Lip 1.72” (171255UC)
11088
----
----
Seal - Triple Lip 2.25 (225255UC)
----
11086
11086
# Description
3,500#
6,000#
6,000#
2D
2D
4A
4B
4C
4D
5
2
2A
2B
2C
3
17
16 15
14
1
13
3,500# Axle,
9.6” Rotor
Mounting Bracket
6,000# Axle,
12” Rotor
Mounting Brackets
6,000# Axle,
11.5” Rotor
Mounting Brackets
12 11 10 9
6
7
7
7
6
6
6
8
10
