Typical brake line placement – Tie Down LP750 User Manual
Page 9
Page 9
To pump master cylinder, insert a flat tip screwdriver into the round
hole on “LEFT” (Drivers side) of the actuator cover. (see right). Standing
in front on the actuator, place one hand on the E-Stop Release witch is
located under the coupler housing.
Bleeding access hole is located on the drivers side
in the middle of the Actuator
Actuator
Brake Line
Connector
Connector
Connector
End Bleeder
Typical Brake Line Placement
Front - Trailer
Rear - Coupler
