10
FieldPilot ®
iNstAllAtioN
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to
the changes in component specifications the parts supplied in the kit are not exactly as presented
in this document, please contact your dealer or TeeJet Customer service representative for
clarification before installation. TeeJet Technologies is not responsible for misuse or incorrect installation of
the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY
DON’T INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
Overview of the Machine
• The FieldPilot valve will mount at the rear of the machine.
• Hydraulic connections will be made at the rear of the machine and at the articulation cylinders.
• The GPS antenna will mount on the hood.
• The cables will enter the bottom-right-rear of the cab
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-3: Overview of the Machines
GPs
Cable
entrance
Hydraulic
Connections
FieldPilot
Valve
