FieldPilot ®
98-05154 R1
Kit Contents
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ..........................................................................................1
B 350-0037 Washer, Flat - 3/8” SST ...............................................................................................2
C 35-02183 Valve, FieldPilot, PWM, 1.1GPM, OC ..........................................................................1
D 45-07703 Harness, SCM .............................................................................................................1
E 45-10103 Harness, Valve .............................................................................................................1
F 60-04089 Bolt, Hex- 3/8-16 x 3-3/4” SST .....................................................................................2
G 60-07027 Nut, NyLock 3/8-16, SST .............................................................................................2
H 65-05169 Bracket, Hydraulic. Block .............................................................................................1
I 68-01102 Hose, Hydraulic - 3/8” x 22”, #6FJIC x #6FJIC 90º .....................................................1
J 68-01166 Hose, Hydraulic - 1/4” x 32” #4FJIC x #4FJIC 90º .......................................................2
K 68-01186 Hose, Hydraulic - 1/2” x 70”, #8FJIC x #8MJIC ..........................................................1
L 68-01187 Hose, Hydraulic - 1/2” x 85”, #8FJIC x #8FJIC 90º .....................................................1
M 68-02008 Adapter, Hydraulic Run Tee - #4 JIC............................................................................2
N 68-02022 Adapter, Hydraulic Run Tee - #6 JIC............................................................................1
O 68-02082 Adapter, Hydraulic - #6MJIC x #8MORB .....................................................................1
P 68-02092 Adapter, Hydraulic 45º - #8MJIC x #8FJIC ..................................................................1
Q 68-02093 Adapter, Hydraulic 90º - #8MJIC x #8FJIC ..................................................................2
R 68-02122 Adapter, Hydraulic - #8MJIC x #12MORB ...................................................................2
S 68-02175 Adapter, Hydraulic - #4MJIC x #8MORB .....................................................................2
T 90-50013 Cable Tie Kit, 15 ..........................................................................................................1
U 91-07011 Steering Wheel Switch Kit ...........................................................................................1
V 98-05154 Installation Manual, FieldPilot Case SPX 3150/3185 ..................................................1
