17

FieldPilot

®

98-05154 R1

11. VeriFY oPeration oF hYdraulics and set the steering

control rate

Clean and pick up the area around the vehicle and make certain that it is safe to operate. Start the engine and

check hydraulic connections for leaks. Rotate the steering wheel from one extreme to the other and back to

center, check for leaks. While steering through the extremes of movement, check the cables and hoses for wear

points and strain, adjust as necessary.

The final oil flow rate adjustment is accomplished through the Matrix console. The

target lock to lock time is 6-8 seconds and the valve frequency is 110. Refer to the

Matrix manual for further instructions.

NOTE: To activate the manual overrides, a tool such as a small screwdriver or allen wrench must be inserted into

the end of the coil to depress the override button.

WARNING: PINCH POINT HAZARD! To prevent serious injury or death, avoid unsafe practice while

manually operating hydraulic steering circuits. Keep others away and stay clear of mechanical steering

linkages.
