4
www.teejet.com
RX370P
RX370p Placement
Placement of the RX370p is crucial to the system’s operation. The GPS engine inside the RX370p computes a
position based upon measurements from each satellite to the internal GPS antenna unit. Mount the RX370p to
the identified point of interest. When choosing a location, make certain there is an unobstructed view of the sky
available to the smart antenna. This will ensure that the GPS satellites are not masked by obstructions, which can
potentially reduce system performance.
To place the RX370p:
1. Mount the RX370p on, or as close to the center of the point of measurement.
2. Position the RX370p as high as possible.
The following illustration provides an example of the ideal location for vehicle placement.
Figure 1-2: RX370p Vehicle Placement
