13
RX370P
98-05106 R1
aPPenDIx B - sPeCIfICatIons
The following tables provide the power, mechanical, communication, environmental and DGPS specifications for
the RX370p.
Table 1-9: Power Specifications
Item Specification
Input Voltage 7-36 VDC
Power Consumption < 2 W @ 12 VDC (typical)
Current Consumption 150 mA 12 VDC (typical)
Power Connector Cable mount environmentally sealed
Table 1-10: Mechanical Specifications
Item Specification
Height 2.2 in (54.7 mm)
Width 5.1 in (129.5 mm)
Weight 1.45 lb (0.66 kg)
Mounting Options Magnetic Mount, Fixed Mount -low or high pole
Table 1-11: Communication Specifications
Item Specification
Serial Ports 2 full duplex RS232
CAN NMEA 2000 broadcast
Pulse Output 1 PPS (HCMOS, active high, rising edge sync)
Baud Rates 4800-57600
Differential Correction I/O
Protocol
RTCM SC-104
Data I/O Protocol NMES 0183, SLX binary and NMEA 2000
Ground Speed Output
Range: 0.5 - > 200 mph (0.8 - > 322 Km/h)
Signal: Opto-isolated pulse out
Frequency Conversion: 28.65 pulse per ft traveled (94 Hz/m/s)
Event Mark Output HCMOS, active low, falling edge sync, 10 k-ohm, 10 pF load
