aPPenDIx D - IllUstratIons
Table 1-14: CenterLine with SmartPad II with RX370p System Configuration
GPS Data IN
Po w er O ut
S m
ar
tP
ad
II
C en
te
rL
in
e
45
-0
53
38
Receicer
78-00027
45-05337
45
-0
53
24
45-05337
W ar ni ng
45
-0 52
98
CenterLine Lightbar
78-50111
RX370p Receiver
78-50148
Cable, GPS Data
45-05338
- OR -
Cable, GPS Data
45-05337
RX410p Receiver
78-50159
Cable, 2 Position
Battery
45-05298
Cable, Power
45-05324
Switchbox Ignition On/Off
78-00027 (Optional)
5 Amp
Status Detect IGN Sense
Power In
+12 v
SmartPad II
75-30005
SmartPad II/CL
Lightbar Cable
45-05427
