TeeJet 834 Sprayer Control - Manual (Page 8)

MI 834 Programming and Operating Manual 9/99 Page 8 of 15
T
IP
S
PACING
Default = 20 inches
Use the
+
or keys to adjust this value.
Once the correct units have been selected,
press the key to advance to the next step.
The value shown is represented in inches.
P
RESSURE
R
EGULATING
M
ODE
Default = byP
The default value "byP" indicates that the pressure
regulating valve is plumbed in a bypass line. If the
default value is correct, press the key.
Use the
+
or keys to change the
value to throttle (tHr) mode if needed.
Note: This setting must match the actual plumbed mode of the regulating valve.
Changing this setting will only reverse the polarity to the valve, it will not effect the
physical operation of the valve. Refer to the plubing diagrams in the Plumbing and
Installation Manual supplied with this unit.
A
PPLICATION
U
NITS
Default = US
Select the application units to be used for
regulation. If you will be using US units (GPA)
Press the key to advance to the next
step. If you will be using trf units (G/1000 ft
2
)
use the
+
or keys to select this value.
Once the correct units have been selected,
press the key to save this parameter and to return to the normal working mode.
Tip
select GPA MPH PSI
On
tip spacing
(inch)
speed cal
(pulses/300ft.)
PROGRAM MODE push 3 sec.
density
byp
Tip
select GPA MPH PSI
On
tip spacing
(inch)
speed cal
(pulses/300ft.)
PROGRAM MODE push 3 sec.
density
20
Tip
select GPA MPH PSI
On
tip spacing
(inch)
speed cal
(pulses/300ft.)
PROGRAM MODE push 3 sec.
density
US
