Kit Contents
Unpack the installation kit and identify the required parts.
Item Part Number Description
Quantity
1 67-20003 Male Connector, Nylon ............................................................................................1
2 67-20002 Tubing Nut, Nylon ....................................................................................................3
3 65-50005 Tubing Insert, Brass .................................................................................................4
4 64-50023 Mounting Bracket, Nylon ..........................................................................................1
5 60-10026 Lock Knob ................................................................................................................2
6 60-50000 ¼″ External Tooth Lock Washer ..............................................................................2
7 60-50003 1″ Bolt, Steel, Zinc Plated ........................................................................................2
8 60-50001 Flat Washer, Steel, Zinc Plated ................................................................................2
9 60-50009 Lock Washer, Steel, Zinc Plated ..............................................................................2
10 350-0062 Hex Nut, Steel, Zinc Plated ......................................................................................2
11 67-20001 Male Coupling, Nylon ...............................................................................................1
12 90-50141 Accessory Bag - Items 2, 3 ,5, & 7-13 .....................................................................1
13 75-50061 TeeJet 744E - 5 sections console, 100 PSI .............................................................1
75-50060 TeeJet 744E - 3 sections console, 100 PSI .............................................................1
14 98-70030 744E Manual ............................................................................................................1
Item Part No. Description Illustration
1 67-20003 Male Connector, Nylon
2 67-20002 Tubing Nut, Nylon
3 65-50005 Tubing Insert, Brass
