744E Sprayer Control
98-70030 R0
CHAPTER 1 - INTRODUCTION
The 744E Sprayer Control provides manual spray control in a compact package.
The console features a lighted pressure gauge for night use and heavy-duty switches with LED indicators.
• Manual spray controller in a compact package.
• 3 or 5 sections control
• Liquid filled 100 PSI (7 bar) pressure gauge
• Lighted pressure gauge for night use
• Heavy-duty switches with LED indicators
• Available in a variety of kit forms using ball valve control manifolds
• Kits include wiring harness
Figure 1-1: 744E Sprayer Console
Pressure gauge Master switch Pressure adjust switch
Boom control switches
