Connection diagrams

Play Acoustic – Reference manual (2014-07-16) 26

Guitar and vocals via FX150

and stereo out to a PA

In this setup, you can use the Headphone Out
from Play Acoustic to send Guitar, Vocal and Aux
signals to your FX150 and send a stereo mix to
the PA via the Play Acoustic XLR outputs.

FX150

Setup example: Guitar and vocals via FX150 and stereo out to a PA
