Introduction
Play Acoustic – Reference manual (2014-07-16) 8
Diagrams
On the following pages, you will see some con-
nection diagrams. We have set things up to give
you clear and concise representations of what
goes where.
There are a few things we would like you to keep
in mind as you look at the diagrams:
1. Inputs to Play Acoustic will be to the left of the
back panel image.
2. Outputs from Play Acoustic will be to the right
of the back panel image.
3. There are two boxes on the bottom of each
diagram.
► The Play Acoustic box shows “what you
hear” from your Play Acoustic headphone
output.
► The P.A. box shows “what you hear” from
the P.A. speakers.
4. We don’t account for other inputs/instruments
when showing “what you hear” from the P.A.,
so you won’t see pictures of drums etc.
5. In a lot of cases, “what you hear” will be the
same for both Play Acoustic headphone out-
put and P.A. – but it can also be different.
3
4 5 5
PLAY ACOUSTIC
