Sonoma CGR30
Natural Gas Conversion Instructions
Be sure gas supply is off, the knobs are in the off
position and the grill is cool.
1. Remove cooking grates and top flavor grids (See
Fig. 1)
2. Remove bottom flavor grids (See Fig. 2)
3. Remove the screws holding the rear heat shield in
place. Lift out rear heat shield and set aside.
(See Fig. 3)
4. Remove the two screws holding each ignitor in
place. (See Fig. 4)
5. Lay ignitors on floor of grill. (See Fig. 5)
* 1/4” socket set with extension can also be used.
Tools Needed:
Phillips head screwdriver
1/4” nut driver *
9/32” or 7mm nut driver *
Adjustable wrench
Fig 5
Fig 1
Fig 2
Fig 3
Fig 4
Screws
Rear Heat Shield
Top Flavor
Grids
Bottom
Flavor Grids
Screws
