Sure Heat Sonoma CGR30 Natural Gas Conversion Kit - Manual (Page 11)

Sonoma CGR30
Natural Gas Conversion Instructions
Converting the Rear Infrared Burner to NG
1. Remove the four (4) screws on the inside of the grill
that hold the rear infrared cover in place. (See Fig. 37)
2. Close the grill hood slowly,
3. Remove the two (2) screws from the back infrared
cover, located on the back of the grill. (See Fig. 38)
4. Grasp rear infrared cover and remove it from the grill.
(See Fig. 39)
5. Disconnect flex line and twist orifice elbow to remove
LP orifice.
6. Completely remove the LP orifice from the flared fitting
and set aside. (See Fig. 40)
7. NG orifice (See Fig. 40)
8. Install the NG orifice into the flared fitting and tighten
completely with an adjustable wrench.
8. Replace the rear infrared cover (See Fig. 39, again)
9. Install the two (2) screws on the back infrared cover,
located on the back of the grill. (See Fig. 38)
10. Open hood.
11. Reinstall the screws that hold the rear infrared cover
in place. (See Fig. 37, again)
12. Rear Infrared Burner conversion complete.
13. This completes the conversion, a leak test should be
performed on all fittings. See Use and Care manual
for leak testing procedure
Fig 37
Fig 39
Fig 40
Screws
NG orifice
Fig 38
RMP-122-30COCI
02/9/05
