Specialty Concepts ASC - Manual (Page 7)

FIGURE 1 ASC Controller
FIGURE 2 ASC Controller with Option-E (LVD)
FUSE RATINGS:
A = Rated for ASC
B = Rated for load
A
C
A
BATT (-)
ARRAY (-)
ARRAY (+)
BATT (+)
COM
N / C
N / O
BATT (-)
ARRAY (-)
ARRAY (+)
BATT
(+)
SOLAR PANEL ARRAY
+
+
LOAD
BATTERY
+
B
A
SOLAR PANEL ARRAY
+
+
LOAD
BATTERY
+
FUSE RATINGS:
A = Rated for ASC
C = Rated for load,
up to 10 amps max. Temp.Sensor
(Optional)
Temp.Sensor
(Optional)
