S
PECIALTY
C
ONCEPTS
M
ODEL
2
(
SC2
)
Photovoltaic Battery Charge Controller
Installation And Operation Manual
S
PECIALTY
C
ONCEPTS,
I
NC.
8954 Mason Ave.
Chatsworth, CA 91311 USA
MODELS: SC2-12, SC2-24, SC2-36, SC2-48 Copyright 10 / 1997 Specialty Concepts, Inc.
G E N E R A L D E S C R I P T I O N
The SPECIALTY CONCEPTS CHARGER MODEL 2 (SC2) is a versatile, industrial quality
charge controller for the efficient use of photovoltaic energy and the protection of expensive
batteries. It is available for 12, 24, 36, and 48 volt systems with models for 30 amps of charge
current (optional 50 amps available for 12 and 24 volt units).
The SC2 consists of a series-relay battery charge controller in a wall mount chassis and a
system status light. The “CHARGE MODE” light indicates the charging condition. The SC2 is
housed in an anodized aluminum chassis and has a terminal block that accepts up to 10
gauge wire. A terminal adapter kit is included to increase wire size to #6.
F E A T U R E S
CHARGE REGULATION
•
30 amp charge current, 12, 24, 36 or 48 volt
•
50 amp charge current (option), 12 or 24 volt
•
Two-step, series charging, 12 and 24 volt
•
Single step, series charging, 36 and 48 volt
•
Adjustable charging set-points (option)
•
Temperature compensation (option)
DESIGN FEATURES
•
Reverse polarity protection
•
Reverse leakage protection
•
Lightning protection
•
Input noise suppression
•
Remote battery voltage sense
MONITORING
•
Charging light
•
Analog volt/amp meters (option)
MOUNTING OPTIONS
•
Indoor wall mount
•
Outdoor enclosure available
(accessory)
