Specialty Concepts ASC - Manual (Page 2)

Web-site: www.specialtyconcepts.com
12 / 2001
PARAMETERS UNITS NOMINAL VOLTAGES
6 v 12 v 24 v 36 v 48 v
Charge Current, Short Circuit, Continuous Refer to Serial Number Tag (available in 1 – 20 amps)
Charge Current, Short Circuit, Max.(60 sec) 1.30% of rated charge current
Load Current, Continuous (1)(2) (Amps) N/A 10 10 N/A N/A
Load Current, Max (60 seconds) (1)(2)(3) (Amps) N/A 13 13 N/A N/A
Array Voltage, Max Voc (Volts) 26 26 46 69 92
Voltage @ Battery
for Charging, Minimum (Volts) 0 0 0 0 0
Voltage @ Battery for LVD, Minimum (1) (Volts) N/A 8.5 17 N/A N/A
Quiescent Current (Milliamps) 10 10 10 10 10
Current Consumption, Charging, Typ. (Milliamps) 15 15 15 15 15
Current Consumption,
Load Disconnected, Typ.
(1)(4) (Milliamps) N/A 40 40 N/A N/A
Voltage Drop, Array to Battery, Typ. (Volts) .30 .30 .30 .60 .60
Voltage Drop, Array to Battery, Max. (Volts) .55 .55 .55 .70 .70
Voltage Drop, Battery to Load, Typ.
(1) ( Volts) . 06 .06 .06 N/A N/A
Charge Termination (5) (Volts) 7.1 + .1 14.3 + .2 28.6 + .4 42.9 + .6 57.2 + .8
Charge Resumption (5) (Volts) 6.75 + .2 13.5 + .3 27.0 + .6 40.5 + .6 54.0 + 1.2
Load Disconnect (LVD) (1) (5) (Volts) N/A 11.5 + .2 23.0 + .4 N/A N/A
Load Reconnect (1) (5) (Volts) N/A 13.0 + .3 26.0 + .6 N/A N/A
Operating Temp. Range ( ° C) -40 to 50 -40 to 50 -40 to 50 -40 to 50 -40 to 50
Storage Temp. Range ( ° C) -55 to 85 -55 to 85 -55 to 85 -55 to 85 -55 to 85
Temperature Comp. Coef. (from 25 ° C) (6) (Volts/ ° C) - .015 -.03 -.06 -.09 -1.2
Notes: (1) Low-voltage disconnect option. 10 amp load.
(2) Non-inductive.
(3) Carry only, Non-switching
(4) LVD relay energized, red L.E.D. on, typical value.
(5) Value adjustable with Adjust. Voltage Set-point option. Charge Termination / Resumption
(and Load Disconnect / Reconnect (Option E)) span is fixed
(6) Temperature compensation option
ASC - Specifications
OPTIONS
A - Temperature Compensation
E - Low-voltage Disconnect (LVD)/
Generator Start
F - Adjustable Voltage Set-point(s)
S - Special or Custom unit
PART NUMBERING KEY
Model
EXAMPLE: Nominal Voltage
Nominal Current
Option
ASC- 12 / 8 - A
