Specialty Concepts BS User Manual

Attery, Aver

background image

B

ATTERY

S

AVER

(

BS

)

Photovoltaic Low-voltage Load Disconnect Device (BS1) (or)

Photovoltaic Low-voltage Generator Start Device (BS6)

Installation and Operation Manual

S

PECIALTY

C

ONCEPTS,

I

NC.

8954 Mason Ave.

Chatsworth, CA 91311 USA

MODELS COVERED: BS1 and BS6 (12, 24, 36, 48 volt units) Copyright 9/1997 Specialty Concepts, Inc.

GENERAL DESCRIPTION

The BATTERY SAVER (BS) is a versatile device for the protection of batteries from low voltage.
Versions can be ordered to disconnect a load or start a generator.

The BATTERY SAVER consists of a relay with a voltage sensing circuit and a red light to indicate
operation. It is housed in an anodized aluminum chassis suitable for wall mounting with a terminal
block for up to 10 gauge wire or spade connector.

FEATURES

LOW-VOLTAGE LOAD DISCONNECT (BS1) or
LOW-VOLTAGE GENERATOR START (BS6)

25 amp load, 12 or 24 volt

15 amp load, 36 or 48 volt

DESIGN FEATURES

Indicator light

Input noise suppression

Reverse polarity protection

Adjustability; set-point and span

Indoor wall mount chassis
