Page 6
1-Way Wireless RF Touchpanel
Crestron ST-1700C
Specifications
Specifications for the ST-1700C are given in the following table.
ST-1700C 1-Way Wireless RF Touchpanel Specifications
SPECIFICATION DETAILS
Power Options
ST-BTPN (or equivalent)
AC: Domestic External Adapter
AC: International External Adapter
ST-DSN
Rechargeable NiMH battery pack (included)
(4100 mAh capacity after full charge. Operating time
depends on usage.)
1
12VDC, 1.5A, 120VAC Input (included)
(P/N PW-1215 or equivalent)
12VDC, 1.5A, 230VAC Input (included with international
version touchpanel)
(P/N PWI-1215 or equivalent)
Docking Station/charger with external power pack
(included)
Default NET ID
3
Default RF ID
10
Default Timeouts
10 minute for standby
30 minutes for power down
Signal Join Maximums
999 digital
Control System Update Files
2, 3, 4
2-Series Control System Update
CEN/CN-TVAV Update File
CNMSX-AV/Pro Update File
CNRACKX/-DP Update File
ST-CP Update File
Version C2-2004.CUZ or later
Version 5.10.13V.UPZ or later
Version 5.10.11X.UPZ or later
Version 5.10.11W.UPZ or later
Version 4.02.02S.UPZ or later
Acceptable File Extensions
6
.vtz
.csf
projectname.vtz (compiled file)
ST1700C.vx.xxx.x.csf (panel firmware)
RF Specifications
1-Way Wireless RF Touchpanel, 433.92 MHz, Range
up to 300 feet
5
Memory
4 MByte flash memory (3 Mbytes available for user
programming)
8 MByte SDRAM for firmware storage
EEPROM for NV storage of last page and join #s
Touchscreen Dimensions
Height: 3.700 in (9.017 cm)
Width: 4.700 in (11.938 cm)
Touchscreen Resolution
320 x 240 pixels, 64K color ISYS engine
Touchscreen LCD
STN color, dot matrix type
Touchscreen Illumination
Backlit fluorescent
Touchscreen Composition
Resistive Membrane
Operating Temperature
50° to 113°F (10° to 45°C)
Humidity
10% to 90% RH (non-condensing)
Overall Dimensions
Width: 8.75 in (22.23 cm)
Height: 3.62 in (9.19 cm)
Depth: 5.43 in (13.79 cm)
Weight (without battery pack)
1.85 lb (0.84 kg)
1.
Battery life is 180 minutes continuous usage with background lighting at full brightness. Actual operating
time depends on usage and settings for background brightness and timeouts.
2.
The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website
(
to NOTE after last footnote.
3.
Crestron 2-Series control systems include the AV2, PAC2, PRO2, and RACK2.
4.
CNX update files are required for either CNMSX-AV/Pro or CNRACKX/-DP. Filenames for CNX update
files have a UPZ extension and ST-CP files are in one EXE or zipped UPZ file. To avoid program
problems, make certain you are using the update file with the correct suffix letter (e.g., S, V, W, X).
2
• 1-Way Wireless RF Touchpanel: ST-1700C Operations
Guide – DOC. 6050
