1-Way Wireless RF Touchpanel Crestron ST-1700C
Setup
Applying Power
The touchpanel can be powered via an external AC power pack, while resting in the
ST-DSN, or via the ST-BTPN. Each of these supplied items has its own Operations
Guide which details proper usage. Refer to the table below for the required document
number.
NOTE: The battery can be charged only if the touchpanel is in the docking station.
The touchpanel will function when powered by the external power pack, but this
configuration will not charge the battery.
ST-1700C Power Source Options
POWER SOURCE OPTION MODEL
DOCUMENT
NUMBER *
Battery Pack ST-BTPN 6088
Docking Station ST-DSN 6095
Domestic External Power Pack or PW-1215 5762
International External Power Pack PWI-1215 5763
* The latest revision may have a revision letter after the document number (i.e., 6088A) .
Identity Codes
The ST-1700C touchpanel uses two distinct types of identity codes: Cresnet identity
(NET ID), and RF ID. These codes are assigned to the touchpanel from the Interface
Submenu when the unit is configured. Refer to “Setup Menu” on page 7. For the
touchpanel to be identified within the Cresnet system, these assignments must match
assignments made in the SIMPL
™ Windows ® program.
NET ID
Every equipment and user interface within the Cresnet system requires a unique NET
ID. The NET ID is a two-digit hexadecimal number that can range from 03 to FE. The
NET ID of the unit must match the NET ID specified in the SIMPL Windows program.
The NET ID is used when the touchpanel is wired directly to the control system during
uploading a VisionTools
™ Pro-e (VT Pro-e) project or upgrading the touchpanel
firmware.
RF ID
Every ST-1700C touchpanel communicating with a Cresnet control system via a
CNRFGWA requires a unique RF ID to secure RF communications. There are 15
useable codes for multiple touchpanel(s) ranging from 01 to 0F (hexadecimal number).
The RF ID of the unit must match the RF ID specified in the SIMPL Windows
program.
NOTE: Do not set the RF ID to “00”; it is not supported in SIMPL Windows.
6 • 1-Way Wireless RF Touchpanel: ST-1700C Operations Guide – DOC. 6050
