• Batch Set Point - This setting is used to set the trip point for regeneration when in flow meter
operation. It will only appear if a flow meter is connected. The programmed setting displays the
actual set point to trigger regeneration. The display will show the “REGEN” icon and “bAtch”
for two seconds and then display the “REGEN” and “GALLONS” or “LITERS” (depending on dip
# 7 setting) icons and the setting numbers to adjust. Adjust the value with the “Up” or “Down”
keys.
Pressing the “Program” key will save the setting and exit the programming menu.
• Save - This setting is used to save customized outputs.
Selecting “Y” saves customized settings; selecting “N”
recalculates outputs based on current inputs (This option
does not appear if outputs are unchanged.).
Pressing the “Program” key will move to the next
programming step.
25
