Bactrox Operations Manual 5
Figure 5. Pass Box
The PASS BOX provides ability to take material into and out of the chamber. PASS BOX can be operated either
automatically or manually. The PASS BOX shelf allows for materials to be conveniently rolled from the PASS
BOX into the chamber.
Figure 6: Incubator Bottom Shelf Spacer
Three (3) are provided with the Bactrox. Refer to Section 8 for installation and precautions.
Inner Airlock Door
Oxygen
Sensor and
Box
Incubator
