16 |

P a g e

INSTALLATION (CONTINUED)

W

ORKSPACE

C

HAMBER

O

RIENTATION

Figure 1: Workspace Chamber Layout

P

ASS

B

OX

O

RIENTATION

Figure 2: Pass Box Inner Door and Sliding Shelf

The pass box is provided with an integral sliding shelf to facilitate material transfers. Small items
may be introduced into the chamber via the Arm Port Doors and Sleeve Assemblies using proper
sleeve technique.

Catalyst

Cartridge

and

Handel

Data Plate
