7
Ref. Dimension
A 2 in . / 51 mm
B 3 .25 in . / 83 mm
C 0 .4375 in . / 11 mm
Ref. Dimension
A 4 .25 in . / 108 mm
B 5 .375 in . / 137 mm
C 2 .125 in . / 54 mm
Dometic flush switch/status panel
(fig . 3
, page 2)
Control module (fig . 4
, page 2)
Ref. Dimension
A 18 in . / 457 mm
B 14 .75 in . / 375 mm
C 19 .75 in . / 502 mm
D 17 in . / 432 mm - seat height
E 16 in . / 406 mm
F 33 .5 in . / 851 mm - seat lid up
Ref. Dimension
A 15 in . / 381 mm
B 14 .75 in . / 375 mm
C 19 .75 in . / 502 mm
D 14 in . / 356 mm - seat height
E 15 .375 in . / 391 mm
F 30 .5 in . / 775 mm - seat lid up
Models 8670, 8679, 8680, 8689
(standard height) Models 8630, 8639, 8640, 8649
(low-profile height)
SeaLand MasterFlush Toilet Specifications
