4
R6GI SERIES SINGLE PACKAGE , MULTI-STAGE, VARIABLE SPEED INVERTER
DRIVEN SYSTEM WITH GAS HEATING / ELECTRIC COOLING
ITEM DESCRIPTION
R6GI-
E24K080X
R6GI-
E36K100X
R6GI-
E48K120X
R6GI-
E60K120X
921275 921276 921277 921278
76
E
LECTRONIC
E
XPANSION
V
ALVE
,1.8 669905 669905 – –
E LECTRONIC E XPANSION V ALVE , 2.4 – – 669906 669906
77
E LECTRONIC E XPANSION V ALVE C OIL , 1.8 669760 669760 – –
E
LECTRONIC
E
XPANSION
V
ALVE
C
OIL
, 2.4 – – 669759 669759
78 EXV PRESSURE TRANSDUCER 624692 624692 624692 624692
79 HARNESS, EXV PRESSURE TRANSDUCER (NOT SHOWN) 634800 634800 634800 634800
80
COMP, SAMSUNG, UG8T265FUAJW 622515R – – –
COMP, SAMSUNG, UG5T360FUAFK – 622516R – –
COMP, SAMSUNG, G5T450FUAAFX – – 622517R –
COMP, SAMSUNG, G5T520FUBFX – – – 622518R
81
HARNESS, COMPRESSOR, SHIELDED (NOT SHOWN) 634819 634819 634819 –
HARNESS, COMPRESSOR, SHIELDED (NOT SHOWN) – – – 634818
82 SWITCH, HIGH PRESS. – AUTO RESET (NOT SHOWN) 632473 632473 632473 632473
83 SWITCH, LOW PRESSURE (NOT SHOWN) 632634 632634 632634 632634
84
GROMMET, COMPRESSOR, (NOT SHOWN) 669914 – – –
GROMMET, COMPRESSOR, (NOT SHOWN) – 690304 690304 690304
85 COMPRESSOR BOLTS (NOT SHOWN) 600419 600419 600419 600419
86
COVER, TERMINAL BOX,COMP (NOT SHOWN) 669949 – – –
COVER, TERMINAL BOX,COMP (NOT SHOWN) – 669916 669916 669916
87
COMPRESSOR SOUND BLANKET, 2 TON (NOT SHOWN) 690526 – – –
COMPRESSOR SOUND BLANKET, 3 & 4 TON (NOT SHOWN) – 690527 690527 –
COMPRESSOR SOUND BLANKET, 5 TON (NOT SHOWN) – – – 690528
88
COMPRESSOR BASE PAD (NOT SHOWN) 690608 – – –
COMPRESSOR BASE PAD (NOT SHOWN) – 689975 689975 689975
89
ACCUMULATOR, STAND PIPE, 41 IN^3 669832 669832 – –
ACCUMULATOR, STAND PIPE, 50 IN^3 – – 669833 669833
90 ACCUMULATOR BRACKET 2B7701 2B7701 2B7701 2B7701
91 DRIER, FILTER, UNIFLOW, 8 IN^3 669764 669764 669764 669764
92
COIL, OUTDOOR, 2 & 3 TON 2B8431R 2B8431R – –
COIL, OUTDOOR, 4 TON – – 2B8441R –
COIL, OUTDOOR, 5 TON – – – 2B8451R
93 REPL. HAIL GUARD KIT (NOT SHOWN) 921213 921213 921213 921213
94
GUARD, COIL (FORMED) (NOT SHOWN) 2B8891R 2B8891R – –
GUARD, COIL (FORMED) (NOT SHOWN) – – 2B8901R –
GUARD, COIL (FORMED) (NOT SHOWN) – – – 2B8911R
95 FAN, GRILLE 669335 669335 669335 669335
96 FAN ORIFICE 295481R 295481R 295481R 295481R
97
MOTOR, OUTDOOR FAN 622648R 622648R – –
MOTOR, OUTDOOR FAN – – 622662R 622662R
98 HARNESS, OD MOTOR, POWER (NOT SHOWN) 634810 634810 634810 634810
99 HARNESS, OD MOTOR, CONTROL (NOT SHOWN) 634811 634811 634811 634811
100 FAN, BLADE 667361 667361 667361 667361
101
PANEL, BLOWER DISCHARGE, 34" 281492 281492 – –
PANEL, BLOWER DISCHARGE, 42" – – 281495 281495
102 BLOWER SHELF 283932 283932 283932 283932
103 CONTROL BLOWER VSHE BOARD 921968 921968 921968 921968
104 CONTROLS BRACKET 2B7871 2B7871 2B7871 2B7871
105 LOW VOLTAGE DIVIDER 2C2341 2C2341 2C2341 2C2341
106 TERMINAL BLOCK, LOW VOLTAGE 632475 632475 632475 632475
107 TERMINAL BLOCK, 2-POLE 632214 632214 632214 632214
108
TERMINAL BLOCK, 2-POLE W/180 OHM RESISTOR 632635 632635 – –
TERMINAL BLOCK, 2-POLE W/300 OHM RESISTOR – – 632659 632659
109 ACCESS FITTING (NOT SHOWN) 663812 663812 663812 663812
Please specify the correct Model No., Serial No, and part number(s) when ordering parts from the nearest authorized dealer or service center.
