R6GI SERIES SINGLE PACKAGE , MULTI-STAGE, VARIABLE SPEED INVERTER
DRIVEN SYSTEM WITH GAS HEATING / ELECTRIC COOLING
ITEM DESCRIPTION
R6GI-
E24K080X
R6GI-
E36K100X
R6GI-
E48K120X
R6GI-
E60K120X
921275 921276 921277 921278
1 ASSY, CAP, DUCT, HORIZONTAL 283101R 283101R 283101R 283101R
2 TOP PAN , INSULATED M0034707R M0034707R M0034707R M007286R
3 FITTING, PANEL 3/8" 664696 664696 664696 664696
4 CORE, CHARGING PORT (NOT SHOWN) 662103 662103 662103 662103
5 PANEL, HEAT EX. DIVIDER D05072R D05072R D05074R D05074R
6 BOTTOM PAN ASSY D05484R D05482R D05482R D05483R
7 RAIL, BASE, 47.23” LG 277551 277551 277551 277551
8 RAIL, BASE, 55.63” LG 277552 277552 277552 277552
9 H ARNESS , DM2F, G ROUND W / FERRITE (NOT SHOWN) 634825 634825 634825 634825
10
DIVIDER PANEL ASSY, 34" M0070201R M0070201R – –
DIVIDER PANEL ASSY, 42" – – M0070203R M0070203R
11 DUCT CAP ASSY. D05530R D05530R D05530R D05530R
12
BLOWER SERVICE PANEL ASSY, 34” D05542R D05542R – –
BLOWER SERVICE PANEL ASSY, 42” – – M0060705R M0060705R
13
FRONT ACCESS, DOOR ASSY, LOUV,34” M0068501R M0068501R – –
FRONT ACCESS, DOOR ASSY, LOUV,42” – – M0068503R M0068503R
14
SUPPLY PANEL ASSY, 34" D05552R D05552R – –
SUPPLY PANEL ASSY, 42" M0060706R M0060706R
15
RETURN PANEL ASSY,34” M0068601R M0068601R – –
RETURN PANEL ASSY,42” – – M0068603R M0068603R
16
CORNER PANEL ASSY, 34” D05628R D05628R – –
CORNER PANEL ASSY, 42” – – M0060708R M0060708R
17
ASSY, CLOSE–OFF PANEL, 34” M0068701R M0068701R – –
ASSY, CLOSE–OFF PANEL, 42” – – M0068703R M0068703R
18 PAN, DRAIN 669190 669190 669190 669190
19 TUBE, DRAIN 656369 656369 656369 656369
20
POST, CORNER, 34" D09996R D09996R – –
POST, CORNER, 42" – – 2B1941R 2B1941R
21
PANEL, CONTROL BOX, 34" 2B5861R 2B5861R – –
PANEL, CONTROL BOX, 42" – – 2B5863R 2B5863R
22 HINGE, LEFT, LONG PIN 669900 669900 669900 669900
23 HINGE, LEFT, SHORT PIN 669901 669901 669901 669901
24 HINGE, RIGHT, NO PIN 669902 669902 669902 669902
25
ACCESS DOOR, INVERTER, 34” 2B8861R 2B8861R – –
ACCESS DOOR, INVERTER, 42” – – 2B8863R 2B8863R
26
ACCESS PANEL, 34” 2B5831R 2B5831R – –
ACCESS PANEL, 42” – – 2B5833R 2B5833R
27 PANEL, HI FLOW 2B5841R 2B5841R 2B5841R 2B5841R
28 CLOSE-OFF, TOP 2B5811 2B5811 2B5811 2B5811
29 CLOSE-OFF, BOTTOM 2B5821 2B5821 2B5821 2B5821
30 BRACKET, LIFT OFF, TOP 2B8881 2B8881 2B8881 2B8881
31 BRACKET, LIFT OFF, BOTTOM 2B8871 2B8871 2B8871 2B8871
32
BLOWER HSG ASSY, 11X8 297217R 297217R – –
BLOWER HSG ASSY, 11X10 – – 297219R 297219R
33
WHEEL, BLOWER 11 X 8 667258 667258 – –
WHEEL, BLOWER 11 X 10 – – 667260 667260
34
INDOOR MOTOR, R6GI, 1/2HP M0071804R M0071804R – –
INDOOR MOTOR, R6GI, 1HP – – M0071805R M0071805R
35 HARNESS, INDOOR MOTOR (NOT SHOWN) 634801 634801 634801 634801
36 HARNESS, DM2F, POWER WIRING W/ FERRITE (NOT SHOWN) 634813 634813 634813 634813
37 HARNESS, DM2F, CONTROL WIRING W/ FERRITE (NOT SHOWN) 634814 634814 634814 634814
38
CONTACTOR, 1P, 30FLA 624713 624713 624713 –
CONTACTOR, 1P, 40FLA – – – 624714
39
TRNSFRM, 208/240/24V, 40VA, 60HZ 622336 622336 – –
TRNSFRM, 208/240/24V, 60VA, 60HZ – – 622335 622335
Please specify the correct Model No., Serial No, and part number(s) when ordering parts from the nearest authorized dealer or service center.
