3
R6GI SERIES SINGLE PACKAGE , MULTI-STAGE, VARIABLE SPEED INVERTER
DRIVEN SYSTEM WITH GAS HEATING / ELECTRIC COOLING
ITEM DESCRIPTION
R6GI-
E24K080X
R6GI-
E36K100X
R6GI-
E48K120X
R6GI-
E60K120X
921275 921276 921277 921278
40
INVERTER DRIVER ASSEMBLY, 2 TON 624762R – – –
INVERTER DRIVER ASSEMBLY, 3 TON – 624763R – –
INVERTER DRIVER ASSEMBLY, 4 TON – – 624764R –
INVERTER DRIVER ASSEMBLY, 5 TON – – – 624765R
41
REACTOR, 2 & 3 TON 624795R 624795R – –
REACTOR, 4 TON – – 624796R –
REACTOR, 5 TON – – – 624797R
42 COMPRESSOR TERMINAL BLOCK 632642 632642 632642 632642
43 OUTDOOR FAN TERMINAL BLOCK, 5 TON – – – 632641
44 SET OF WIRES REPLACEMENT (NOT SHOWN) M0070002 M0070002 M0070002 M0070001
45 TOUCH UP PAINT, GREY (NOT SHOWN) 8983202 8983202 8983202 8983202
46 CONTACTOR, INVERTER, 5 TON – – – 624803
47 PTCR, INVERTER, 5 TON – – – 624804
48
INTERFACE BOARD, 2 TON 624771R – – –
INTERFACE BOARD, 3 TON – 624772R – –
INTERFACE BOARD, 4 TON – – 624773R –
INTERFACE BOARD, 5 TON – – – 624774R
49 THERMISTOR, SENSOR, DISCHARGE TEMP (NOT SHOWN) 624779 624779 624779 624779
50 THERMISTOR, SENSOR, AMBIENT TEMP (NOT SHOWN) 624780 624780 624780 624780
51 THERMISTOR, SENSOR, OD COIL SAT TEMP (NOT SHOWN) 624781 624781 624781 624781
52 THERMISTOR, SENSOR, SUCTION TEMP, 3/4” (NOT SHOWN) 624782 624782 – –
53 THERMISTOR, SENSOR, SUCTION TEMP, 7/8” (NOT SHOWN) – – 624792 624792
54 IGNITION CONTROL, 2 STG, 2 SPD 921967 921967 921967 921967
55 EXHAUST DUCT ASSY. 263420R 263420R 263420R 263420R
56 INDUCER MOTOR, 2 SPD, 230V 921379 921379 921379 921379
57 SWITCH, PRESSURE, DUAL, NO., .50”/.70”W.C. 632555 632555 632555 632555
58 GASKET, COLLECTOR PAN 689506 689506 689506 689506
59 GASKET, INDUCER MOTOR MOUNTING 689518 689518 689518 689518
60
HEAT EXCH. PANEL ASSY, 4 TUBE, 34” M0069001R – – –
HEAT EXCH. PANEL ASSY, 5 TUBE, 34” – M0069002R – –
HEAT EXCH. PANEL ASSY, 5 TUBE, 42” – – M0069003R M0069003R
61
LIMIT S WITCH , MAIN AIR (170/120) 626423 626423 – –
LIMIT S WITCH , MAIN AIR (165/145) – – 626432 626432
62
BURNER ASSY, 2 STG V ALVE , 4 TUBE M0034105R – – –
BURNER ASSY, 2 STG V ALVE , 5 TUBE – 293323R 293322R 293322R
63 LIMIT SWITCH, FLAME ROLLOUT 320º F 626547 626547 626547 626547
64 SENSOR, FLAME 632396 632396 632396 632396
65 BURNER, INSHOT 660812 660812 660812 660812
66
ORIFICE, MAIN BURNER, #43 DRILL (NOT SHOWN) – – 661043 661043
ORIFICE, MAIN BURNER, #45 DRILL (NOT SHOWN) 661045 661045 – –
67
MANIFOLD, GAS , 4 BURNER 664304 – – –
MANIFOLD, GAS , 5 BURNER – 664305 664305 664305
68 IGNITOR 903179 903179 903179 903179
69
GAS VALVE, 2-STAGE, NAT. GAS ONLY 921816 921816 921816 921816
GAS VALVE, 2-STAGE,
W
/ LP REGULATOR SPRINGS 921691 921691 921691 921691
70
PAN, COLLECTOR ASSY, 1.25” ORIFICE D10326R – – –
PAN, COLLECTOR ASSY, 1.5” ORIFICE – D10328R – –
PAN, COLLECTOR ASSY, 1.69” ORIFICE – – M0074321 M0074321
71 COVER, EXHAUST VENT 265240R 265240R 265240R 265240R
72 PANEL, WEATHER 263880 263880 263880 263880
73 SUPPORT, COIL 263394 263394 263396 263396
74
COIL, INDOOR, 2 & 3 TON D13001R D13001R – –
COIL, INDOOR, 4 TON – – 2B1961R –
COIL, INDOOR, 5 TON – – – 2B4001R
75 CONNECTOR, SWIVEL 664194 664194 664194 664194
Please specify the correct Model No., Serial No, and part number(s) when ordering parts from the nearest authorized dealer or service center.
