Form P-OH/, P/N272437, Page 2
Year Jan Feb Mar Apr May June July Aug Sept Oct Nov Dec
1992 ARA ARB ARC ARD ARE ARF ARG ARH ARI ARJ ARK ARL
1993 ASA ASB ASC ASD ASE ASF ASG ASH ASI ASJ ASK ASL
1994 ATA ATB ATC ATD ATE ATF ATG ATH ATI ATJ ATK ATL
1995 AUA AUB AUC AUD AUE AUF AUG AUH AUI AUJ AUK AUL
1996 AVA AVB AVC AVD AVE AVF AVG AVH AVI AVJ AVK AVL
1997 AWA AWB AWC AWD AWE AWF AWG AWH AWI AWJ AWK AWL
1998 AXA AXB AXC AXD AXE AXF AXG AXH AXI AXJ AXK AXL
1999 AYA AYB AYC AYD AYE AYF AYG AYH AYI AYJ AYK AYL
2000 AZA AZB AZC AZD AZE AZF AZG AZH AZI AZJ AZK AZL
2001 BAA BAB BAC BAD BAE BAF BAG BAH BAI BAJ BAK BAL
2002 BBA BBB BBC BBD BBE BBF BBG BBH BBI BBJ BBK BBL
2003 BCA BCB BCC BCD BCE BCF BCG BCH BCI BCJ BCK BCL
2004 BDA BDB` BDC BDD BDE BDF BDG BDH BDI BDJ BDK BDL
2005 BEA BEB BEC BED BEE BEF BEG BEH BEI BEJ BEK BEL
2006 BFA BFB BFC BFD BFE BFF BFG BFH BFI BFJ BFK BFL
2007 BGA BGB BGC BGD BGE BGF BGG BGH BGI BGJ BGK BGL
2008 BHA BHB BHC BHD BHE BHF BHG BHH BHI BHJ BHK BHL
2009 BIA BIB BIC BID BIE BIF BIG BIH BII BIJ BIK BIL
2010 BJA BJB BJC BJD BJE BJF BJG BJH BJI BJJ BJK BJL
2011 BKA BKB BKC BKD BKE BKF BKG BKH BKI BKJ BKK BKL
2012 BLA BLB BLC BLD BLE BLF BLG BLH BLI BLJ BLK BLL
2013 BMA BMB BMC BMD BME BMF BMG BMH BMI BMJ BMK BML
2014 BNA BNB BNC BND BNE BNF BNG BNH BNI BNJ BNK BNL
2015 BOA BOB BOC BOD BOE BOF BOG BOH BOI BOJ BOK BOL
2016 BPA BPB BPC BPD BPE BPF BPG BPH BPI BPJ BPK BPL
2017 BQA BQB BQC BQD BQE BQF BQG BQH BQI BQJ BQK BQL
2018 BRA BRB BRC BRD BRE BRF BRG BRH BRI BRJ BRK BRL
2019 BSA BSB BSC BSD BSE BSF BSG BSH BSI BSJ BSK BSL
2020 BTA BTB BTC BTD BTE BTF BTG BTH BTI BTJ BTK BTL
First Element of the Serial Number - Date of Manufacture
Serial No. Decoding
Example:
BEA 140 0000 B
1 2 3 4
Code:
1 = Date of manufacture (see chart below)
2 = Size (BTUH input)
3 = Consecutive number
4 = Manufacturing designation for oil-fired Models OH
and OB
Sample of a Rating Plate
Rating Plate and Serial Nos.
Rating Plate Key:
A = Model and Size
B = Blower Motor HP
C = Input Amps
D = Minimum Circuit Ampacity (Amps)
E = Maximum Unit Fuse (Amps)
F = Fuel Type (No. 2 Oil)
G = Firing Rate (GPH)
H = Normal BTUH Input (sea level)
I = Thermal Output BTUH (sea level)
J = Nozzle Type (Delevan GPH)
K = Nozzle Spray Angle (Degrees)
L = Oil Pump Pressure (PSIG)
M = Maximum Overfire Pressure (" w.c.)
N = External Static Pressure (" w.c.)
O = Flue Outlet Draft (" w.c.)
P = Burner P/N (Beckett)
Q = Top Clearance (inches)
R = Side Clearance (inches)
S = Used or Not Used with Air Ducts
REZNOR ®
MERCER, PA., U.S.A. 16137
MADE IN MEXICO
OIL FIRED UNIT HEATER
CSA CERTIFIED TO CSA/CAN B140.4 1974
FOR INDUSTRIAL/COMMERCIAL USE ONLY
FOR USE WITH INTEGRAL GROUP 1 OR 2 PRIMARY SAFETY CONTROLS
MODEL [ A ] OIL NOT HEAVIER THAN NO.2
SERIAL NO. [ B ] HP
USE COPPER CONDUCTORS ONLY
115 VOLTS 1 PH 60 HZ [ C ] AMPS
MINIMUM CIRCUIT AMPACITY [ D ] AMPS
MAXIMUM UNIT FUSE [ E ] AMPS
TYPE OF OIL [ F ]
FIRING RATE [ G ] G.P.H.
INPUT [ H ] BTU/HR
THERMAL OUTPUT CAPACITY [ I ] BTU/HR
NOZZLE TYPE; DELEVAN [ J ] G.P.H. [ K ] DEGREES TYPE B
OIL PUMP PRESSURE [ L ] PSIG
MAXIMUM OVERFIRE PRESSURE [ M ] IN.W.C.
EXTERNAL STATIC PRESSURE [ N ] IN.W.C.
FLUE OUTLET PRESSURE RANGE (DRAFT) [ O ] IN.W.C.
BURNER PART NUMBER [ P ] BECKETT
THIS UNIT IS FOR INSTALLATION SUSPENDED FROM A CEILING WITH
CLEARANCES TO COMBUSTIBLES MATERIALS NO LESS THAN.
TOP - [ Q ] BOTTOM - 6" SIDES - 18"
REAR - [ R ] FRONT - 48" FLUE PIPE - 18"
IN CANADA, REFERENCE CSA B139-M91 FOR INSTALLATION IN GARAGES,
ETC.
IN USA, INSTALL UNIT IN ACCORDANCE WITH THE FOLLOWING
STANDARDS;
ANSI/NFPA 409-1990 FOR AIRCRAFT HANGARS
ANSI/NFPA 88A-1991 FOR PARKING STRUCTURES
ANSI/NFPA 88B-1991 FOR REPAIR GARAGES
THIS UNIT [ S ] WITH AIR DUCTS
THIS UNIT IS NOT FOR USE WITH AIR FILTERS.
