Form P-ZQYRA, PN262961R2, Page 1
Form P-ZQYRA (Version A)
Obsoletes Form P-ZQYRA
Applies to: Replacement Parts for
Z Series Model ZQYRA
Ventilation Unit
IMPORTANT
1. Always include complete model and serial
number so that any specification change can
be considered for parts shipment. It can save
time and expense.
2. Specifications are subject to change without
notice.
3. We reserve the right to substitute functional
replacements.
4. Order by Part No.; not Option Designation.
Index
A
Accumulator 7
B
BacNet® Card 3
Belt 6
Wheel Belt 5
Blower Assembly 6
C
Cabinet Parts 8
Cable for Controller 3
Cable Splitter and Signal Booster
4
Check Valve 7
CO2 Sensor 4
Condenser Coil 7
Evaporator Coil 7
Compressor 7
Compressor Digital Controller 3
Connection Cable 4
Contactor 3
Digital Controller 3
Corner Post 8
Cover 8
Crankcase Heater 7
DANGER
This unit contains R-410A high pressure refrigerant. Hazards exist that could result
in personal injury or death. Installation, maintenance, and service should only be
performed by an HVAC technician qualified in R-410A refrigerant and using proper tools
and equipment. Due to much higher pressure of R-410A refrigerant, DO NOT USE service
equipment or tools designed for R22 refrigerant.
IMPORTANT: Do not release refrigerant to the atmosphere! If required service
procedures include the adding or removing of refrigerant, the service technician
must comply with all federal, state, and local laws. Service should only be performed
by a qualified HVAC technician.
D
Damper 5
Discharge Air Temperature
Sensor 4
Disconnect Switch 5
Display 3
Remote Unit Display 4
Distribution Block 3
Door 8
Drain Cover 8
Duct Angle Support 8
E
Electric Heat 5
Electric Heating Element 3
Electric Module Support 5
Exhaust Fan 6
F
Fan Support 6
Fan Support Bracket 6
Filter Drier 7
Filters 8
Fuse 3
Fuse Clip 3
H
Heat Module 5
Exhaust Hood 8
Inlet Air Hood 8
I
Inlet Ring 6
L
Lifting Lug 8
LON® Communication Card 3
M
Damper Motor 5
Wheel Motor 5
Compressor Mounting Kit 7
O
Occupancy Switch 4
Overload Relay 3
P
Panel 8
Molded Plug 7
Dirty Filter Pressure Switch 3
High Pressure Switch 7
Low Pressure Switch 7
R
Rating Plate 2
Relay 3
Relay Module 3
Reversing Valve 7
Roof Curb 8
S
Humidity and Temperature
Sensor 4
Indoor Air Quality (VOC and CO)
Sensor 4
Temperature Sensor 3
Serial No. 2
Shaft Extension 5
Sheave 6
Socket 3
Start/Stop Switch 4
Supply Fan 6
Air Proving Switch 3
T
Temperature Sensor 3
Terminal Block Kit for Controller
3
Thermistor 7
Thermostatic Expansion Valve 7
Time Clock Wall Switch 4
Transformer 3
W
Enthalpy Wheel Cassette 5
Wheel Segment 5
Wheel Supports 5
