Page 8
Table 2. Orifice or Drill Size for Propane (LP) Gases
Unit Model
Number
Gas
Type
Number
of Burners
Gas Valve
Manufacturer
heating Input (Btuh)*
Orifice Size for Increased Elevation
(Above Sea Level)
High Fire
Low Fire
0 to
2,000 Ft
2,001 to
4,000 Ft
4,001 to
6,000 Ft
6,001 to
8,000 Ft
8,001 to
10,000 Ft
R6GP-072*-100C
L.P.
3
Honeywell
85,000
55,250
53
54
54
55
55
R6GP-072*-166C
L.P.
5
Honeywell
141,000
91,650
53
54
54
55
55
R6GP-090*-200C
L.P.
6
Honeywell
175,000
113,750
53
54
54
55
55
White Rodgers
105,000
51
52
52
52
53
R6GP-120*-235C
L.P.
7
White Rodgers
205,000
123,000
51
52
52
52
53
* Refer to Instructions for High Altitude Deration to determine heat-exchanger capacity at increased elevations.
Table 3. heating Rise / Range
MODEL
GAS
TYPE
HEATING
INPUT
HEATING
OUTPUT
HEATING
RISE
RANGE (°F)
CFM RANGE
R6GP-072*-100C
Propane
85,000
68,000
15 -45
1,950
2,100
2,250
2,400
2,550
2,700
SCFM
32
30
28
26
25
23
RISE (°F)
R6GP-072*-166C
Propane
141,000
112,800
35 - 65
1,950
2,100
2,250
2,400
2,550
2,700
SCFM
54
50
46
44
41
39
RISE (°F)
R6GP-090*-200C
Propane
175,000
140,000
30 - 60
2,425
2,625
2,800
3,000
3,188
3,375
SCFM
52
48
45
42
40
38
RISE (°F)
R6GP-120*-235C
Propane
205,000
164,000
25 - 55
3,250
3,500
3,750
4,000
4,250
4,500
SCFM
47
43
40
38
36
34
RISE (°F)
* At elevations of 2,000 feet or less.
Table 4. Unit / valve data - LP gas only
Unit Model
Number
Gas Valve
Manfufacturer
Gas Valve
Model No.
maximum
Inlet Pres. †
minimum
Inlet Pres. †
Factory Set, Manifold
Pres. † High Fire
Factory Set, Manifold
Pres. † Low Fire
R6GP-072*-100C
Honeywell
VR8205Q
14.0 (3.49)
11.0 (2.74)
10.0 (2.49)
4.0 (1.0)
R6GP-072*-166C
Honeywell
VR8205Q
14.0 (3.49)
11.0 (2.74)
10.0 (2.49)
4.0 (1.0)
R6GP-090*-200C
Honeywell
VR8205Q
14.0 (3.49)
11.0 (2.74)
10.0 (2.49)
4.0 (1.0)
R6GP-090*-200C
White Rodgers
36H64
14.0 (3.49)
11.0 (2.74)
9.5 (2.37)
5.0 (1.24)
R6GP-120*-235C
White Rodgers
36H64
14.0 (3.49)
11.0 (2.74)
9.5 (2.37)
5.0 (1.24)
† All Pressure values are expressed in: in-WC (kPa)
709010A
(Replaces 7090100)
