Form I-PREEVA-UV, P/N 220705, Page 1

Installation Form for

Cooling Coil UV Light, Option UV2

Form I-PREEVA-UV

Description and

Application

Option UV2, germicidal ultra-violet light, is designed for installation in Reznor

PREEVA Models PDH, SDH, and RDH with an optional cooling module that has

either a DX or a chilled water coil. The light is installed in the blower section down-

stream from and facing the cooling coil. Option UV2 light requires a separate dedi-

cated power source which may be 115V/1Ph, 208V/1Ph, or 230V/1Ph.
Read this entire instruction manual before beginning installation. Comply with all

warnings and safety considerations.
Reznor, LLC cannot and does not guarantee that all organisms will be inactivated

or killed or that use of Option UV2 light will prevent infection or illness. Additionally,

the health aspects associated with the use of this product and its ability to aid in

disinfection of environment air have not been investigated by UL.

Safety

Considerations

Installation and servicing of air conditioning equipment can be hazardous due to

system pressure and electrical components. Only trained and qualified service

personnel should install, repair, or service air conditioning equipment.
Follow all safety codes. Wear safety glasses and work gloves and cover all exposed

skin when installing or servicing ultra-violet light.

HAZARD INTENSITY LEVELS

DANGER: Failure to comply will result in severe personal injury or

death and/or property damage.

WARNING: Failure to comply could result in severe personal injury

or death and/or property damage.

CAUTION: Failure to comply could result in minor personal injury

and/or property damage.

Definitions

of Cautions,

Warnings, and

Dangers

WARNING

Improper installation, adjustment, alter-

ation, service, or maintenance can

cause property damage, personal injury,

or death. A qualified installer or service

agency must perform installation and

service.

CAUTION

Use only the specified high-output, low

temperature bulbs with this lamp. Use

of a lower wattage or incorrect bulb can

result in damage to the light and/or the

bulb. (See replacement list on page 4.)

WARNING

Before installing or servicing an

Option UV2 light, turn off the main

power switch to both the light fixture

and to the unit. Electrical shock can

cause injury or death.

CAUTION

Never expose eyes or skin to ultra-

violet light from any source. Light

must be off before opening the door

on the blower section, cooling coil

module, optional mixing box, and

optional evaporator cooling module.

Never use the UV lamp for lighting.

Applies to:

Models PDH, SDH, RDH with Cooling Module
