PAGE 9
Mist Elimi na tor Fil ter in In take Hood (2HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 1055 1135 1295 1420 1540 1650 1725
1400 1140 1240 1340 1490 1600 1690 1795
1600 1200 1330 1460 1565 1645 1740 1830
1800 1320 1405 1525 1615 1705 1785 1885
2000 1415 1515 1605 1690 1775 1875 1960
Ba ro met ric Hood, 2" Pleated Fil ters ( 2HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 1010 1195 1350 1445 1580 1685 1735
1400 1125 1315 1435 1545 1620 1730 1800
1600 1185 1370 1500 1610 1695 1790 1965
1800 1305 1485 1600 1685 1781 1955 2030
2000 1410 1550 1670 1765 1855 N/A N/A
SUP PLY
Blower RPM for XBWU20
EXHAUST
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only RPM Range
Low 1000- 1300 Stan dard Unit
Me dium 1300- 1700 Op tional Kit
High 1700- 2080 Op tional Kit
SUP PLY
Blower RPM for XBWU11
EXHAUST
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only RPM Range
Low 1000- 1300 Stan dard Unit
Me dium 1300- 1700 Op tional Kit
High 1750-2200 Op tional Kit
Ba ro met ric Hood, 2" Pleated Fil ters ( 1.5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
300 N/A N/A 1030 1225 N/A N/A N/A
500 N/A 1025 1180 1265 1425 1535 N/A
700 1120 1190 1340 1445 1540 1645 1720
900 1285 1525 1500 1575 1670 1785 1865
1100 1570 1665 1670 1775 1860 1920 N/A
Mist Elimi na tor Fil ter in In take Hood ( 1.5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
300 N/A N/A 1175 1350 1450 1605 1730
500 N/A 1170 1340 1540 1655 1725 1840
700 1295 1425 1600 1625 1795 1960 2035
900 1540 1660 1720 1790 2030 2110 2195
1100 1785 1915 2025 2185 N/A N/A N/A
