Mist Elimi na tor Fil ter in In take Hoo d (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
2000 725 825 900 1000 1070 1180 1250
2400 800 900 1000 1070 1160 1250 1275
2800 900 1000 1070 1160 1250 1275 1340
3200 1000 1070 1160 1250 1275 1340 1400
3600 1055 1180 1250 1300 1360 N/A N/A
Ba ro met ric Hood, 2" Pleated Fil ters (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
2000 750 865 950 1030 1100 1200 1265
2400 820 950 1035 1100 1200 1265 1300
2800 925 1035 1150 1200 1265 1315 1350
3200 1035 1160 1215 1265 1325 1350 1390
3600 1100 1215 1300 1350 1390 N/A N/A
SUP PLY
Blower RPM for XBWU36
EXHAUST
RPM Range
Low 725-975 Stan dard Unit
Me dium 1000-1315 Op tional Kit
High 1215-1425 Op tional Kit
SUP PLY
Blower RPM for XBWU28
EXHAUST
RPM Range
Low 750- 975 Stan dard Unit
Me dium 1008-1314 Op tional Kit
High 1311-1708 Op tional Kit
Mist Elimi na tor Fil ter in In take Hood (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 N/A 790 960 1110 1210 1315 1380
1600 750 900 1005 1145 1230 1365 1410
2000 900 1005 1105 1210 1275 1400 1450
2400 1005 1125 1210 1275 1365 1450 1500
2800 1125 1230 1315 1380 1450 1535 1600
Ba ro met ric Hood, 2" Pleated Fil ters (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 750 885 1015 1145 1260 1350 1485
1600 870 1015 1125 1215 1325 1410 1500
2000 1015 1145 1240 1345 1410 1485 1560
2400 1125 1250 1345 1430 1500 1575 1630
2800 1250 1410 1485 1520 1630 1650 1675
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only
