PAGE 11
Mist Elimi na tor Fil ter in In take Hood (5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
4600 815 900 975 1045 1085 1125 1175
5000 880 940 1015 1060 1135 1175 1215
5400 915 975 1045 1125 1150 1195 1250
5800 975 1045 1085 1175 1250 1260 N/A
6200 1000 1075 1165 1200 N/A N/A N/A
Ba ro met ric Hood, 2" Pleated Fil ters (5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
4600 825 915 1000 1025 1100 1140 1170
5000 890 975 1025 1100 1140 1170 1240
5400 925 1000 1085 1140 1170 1240 1280
5800 975 1025 1140 1170 1240 N/A N/A
6200 1025 1120 1170 N/A N/A N/A N/A
SUP PLY
Blower RPM for XBWU62
EXHAUST
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only RPM Range
Low 820- 1000 Stan dard Unit
Me dium 1000- 1200 Op tional Kit
High 1175- 1375 Op tional Kit
SUP PLY
Blower RPM for XBWU46
EXHAUST
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only RPM Range
Low 780- 1020 Stan dard Unit
Me dium 1000- 1315 Op tional Kit
High 1315- 1700 Op tional Kit
Mist Elimi na tor Fil ter in In take Hood (5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
3000 900 1030 1100 1165 1240 1285 1350
3400 975 1085 1175 1240 1290 1350 1400
3800 1070 1175 1240 1290 1350 1400 1465
4200 1165 1240 1320 1350 1430 1465 1515
4600 1240 1320 1375 1430 1500 1515 1580
Ba ro met ric Hood, 2" Pleated Fil ters (5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
3000 955 1100 1160 1245 1280 1360 1425
3400 1055 1185 1245 1300 1375 1425 1480
3800 1160 1300 1360 1400 1425 1530 1585
4200 1245 1375 1450 1480 1500 1585 1650
4600 1360 1450 1500 1585 1600 1650 1700
